Signal Repeater (Range Extender)

Description
Technical
Description

The Quinetic Signal Repeater enhances the RF signal strength of a Quinetic wireless switch, allowing for wireless control (ON/OFF and dimming) of any Quinetic receiver. It boosts signal quality and range whilst reducing transmission interference.

Capable of pairing with up to 10 wireless Quinetic switches, it extends the signal from the paired switches to the receiver, ensuring reliable performance.

Extended coverage, increased range - Significantly boosts coverage area, enhancing signal strength even in environments with multiple obstacles

Signal boost, quality enhancement - Amplifies and reproduces the signal to overcome attenuation, ensuring consistent signal quality

Compact design, easy installation - Features a sleek and compact size, allowing for quick installation using either adhesive stickers or screws

Enhanced communication, reduced interference - Minimises noise and interference, ensuring more reliable and clear communication

Technical
  • Operating voltage100-240V AC, 50/60Hz
  • Power supplyLive & Neutral cables
  • Communication frequencyRF 433MHz
  • Receiving range (from switch)up to 15m indoors / 30m outdoors
  • Extending range (to receiver)up to 50m indoors / 120m outdoors
  • Standby power consumption<0.4W
  • RatingIP20
  • Operating temperature-20°C to 55°C
  • StandardsCE / ROHS / EN60669-1:2018 / EN IEC55015:2019
  • Warranty3 years
